Specifications:

• Tc of Open Circuit Voltage: (-0.29%/°C)
• Tc of Short Circuit Current: (0.057%/°C)
• Tc of Power: (-0.38%/°C)
• Maximum System Voltage: 1500 V
• NOCT: 44°C ± 2°C
• Temperature Range: -40°C to + 85°C
• Length × Width × Height: 1956 × 992 × 36 mm (77.01 × 39.06 × 1.42 inches)
• Weight: 20.7 kg (45.63 lbs)
• Junction Box: IP68/IP67, 3 Bypass diodes
• Cable & Connectors: 1200 mm (47.24 inches) length cables, MC4 Compatible/MC4 Connectors
• Application Class: Class A (Safety class II)
• Superstrate: 3.2 mm (0.13 inches) high transmission low iron tempered glass, AR coated
• Cells: 72, 5BB Polycrystalline solar cells
• Cell Encapsulant: EVA (Ethylene Vinyl Acetate)
• Back Sheet: Composite film
• Frame: Anodized aluminium frame with twin wall profile
• Mechanical Load Test: 5400 Pa (Snow load), 2400 Pa (Wind load)
• Maximum Series Fuse Rating: 15 A

Features:

• Maximum system voltage increased to 1500VDC (IEC & UL), increased string length, low BOS cost
• Higher output of module power by reducing cell to module power loss
• Efficiency up to 17.26% Range- 315-335W
• Designed for very high area efficiency ideally suited for rooftop and ground-mounted applications
• Extremely Narrow Power Binning Tolerance of +2.5 Wp to reduce current mismatch loss in single string
• 10 years of product warranty and 27 years of linear performance warranty

Applications:

• On-grid large scale utility systems
• On-grid rooftop residential, commercial and industrial solar installations
• Off-grid residential systems
• Solar pumping applications
