Specifications:

• Tc of Open Circuit Voltage: (-0.31%/°C)
• Tc of Short Circuit Current: (0.069%/°C)
• Tc of Power: (-0.40%/°C)
• Maximum System Voltage: 1500 V (IEC & UL)
• NOCT: 45°C ± 2°C
• Temperature Range: -40°C to + 85°C
• Length: 1960 mm
• Width: 992 mm
• Height: 35 mm / 40 mm
• Weight: 22 Kg (35 mm) / 27 Kg (40mm)
• Junction Box: IP67
• Cable and Connectors: 1200 mm Length Cable, MC4 8 Amphenol Compatible Connectors
• Application Class: Class A (Safety Class II)
• Superstrate: High Transmittance Arc Glass
• Cells: 72 Multi-Crystalline Solar Cells; 5 Bus Bars, 156.75 x 156.75 mm
• Cell Encapsulation: Superior Dielectric Strength 8 PID Resistant EVA
• Substrate: Tri layer Backsheet
• Frame: Anodized Aluminium Frame with Twin Wall Profile
• Mechanical Load Test as per IEC & UL: 5400 Pa-front; 2400 Pa-back
• Maximum Series Fuse Rating: 15 A

Features:

• More Power/m2 as compared to industry average
• Higher specific energy yield (kWh/kWp) due to Superior Cell + Module Engineering
• Superior Performance at NOCT and PCT conditions
• Superior low light Irradiation Performance 200W/m2
• 5BB Modules offer better performance against Micro-Cracks as compared to 4BB & 3BB modules
• Triple EL checking to ensure defect free modules
